This small 20m3/h HBT20 mini concrete mixer pump machine is an ideal solution for construction projects involving water conservancy, electricity, railway, highway, tunnels, and mines. It features high efficiency and a reliable hydraulic transmission system.
Equipped with world-class hydraulic oil pumps (Rexroth or Kawasaki). The unique open hydraulic system and cushion technology ensure smaller exchange impact and reduced system heat, guaranteeing long-term reliability.
Uses PLC (Programmable Logic Controller) with components from Schneider, Siemens, and OMRON. Features include manual operation, wireless remote control, and an intelligent 8-digital pumping timer with automatic trouble monitoring.
Patented central automatic lubrication system with a piston grease-pump ensures double protection. The compulsory air-cooled heat exchanger keeps hydraulic oil below 60°C for optimal performance.
| Parameter Item | Specifications (HBT20-10RSD) |
|---|---|
| Max. Theoretical Concrete Output | 21 m³/h (Low) / 12 m³/h (High) |
| Max. Pumping Pressure | 5.5 Mpa (Low) / 10 Mpa (High) |
| Concrete Slump Range | 100-230 mm |
| Max. Aggregate Particles | 25/30 mm |
| Hopper Volume | 0.4 m³ |
| Concrete Cylinder Diameter × Stroke | Φ140×1000 mm |
| Dynamic Power Brand | Diesel Engine (K4102D2) |
| Rated Power | 39.6 kw |
| Hydraulic Oil Tank Volume | 260 L |
| Overall Dimension (L×W×H) | 4300×1670×1680 mm |
| Total Weight | 2500 kg |
For optimal performance, hydraulic oil should be changed every 12 to 18 months or after pumping approximately 15,000 m³. Ensure the system is cleaned using low-viscosity naphthenic base oil during the replacement process. Always check the transparency and color of the oil before disposal.
